FULLRANGE SPEAKER BG13 8Ω
Code GAVSPBG13- Manufacturer VISATON
- ID code 3011
- Weight 465.00g
E-shop price: 21,90 €
Minimum order: 1 Repeatability : 1
Amount
| Item location: | ||
|---|---|---|
| Central warehouse in Kaunas | Item is not available (0) | |
| Shop in Vilnius | Item is not available (0) | |
| Shop in Kaunas | Item is not available (0) | |
Item description
Rated power: 20 W
Opening angle (-6 dB): 61°/4000 Hz
Excursion limit: +/-2 mm
Resonance frequency fs: 168 Hz
Magnetic induction: 1,0 T
Magnetic flux: 190 µWb
Height of front pole-plate: 3 mm
Voice coil diameter: 20 mm
Height of winding: 4,5 mm
Cutout diameter: 110 mm
D.C. resistance Rdc: 5,2 Ohm
Mechanical Q factor Qms: 3,06
Electrical Q factor Qes: 1,58
Total Q factor Qts: 1,04
Equivalent volume Vas: 2,0 l
Effective piston area Sd: 68 cm²
Dynamically moved mass Mms: 3,0 g
Force factor Bxl: 3,2 Tm
Inductance of the voice coil L: 0,65 mH
Temperature range:-25 ... 70 °C
